Create a scroll tracking

min

quiz

Scroll tracking enables you to measure the rate of visitors having scrolled to a certain level on your web page. You can create it via the graphical editor or via the Kameleoon back office.

Just like click tracking a scroll tracking can be created from any of your variations. Once created and associated with your experiment, all its variations will be tracked. You can also use scroll tracking for all new tests.

Access the “Scroll tracking” tool

To set a scroll tracking from the editor, launch Kameleoon in edit mode on the page and variation of your choice.

Select the element you want to associate a scroll tracking to; the tool panel appears. The third tab, “Tracking”, enables you to configure the tracking.

Name your scroll tracking to be able to identify it and in the drop-down menu, select “Scroll tracking”.

Set up a scroll tracking

Selecting “Scroll tracking” gives access to a serie of options in the tool panel. The page is also divided in two:

The upper part is displayed normally and delimits the part of the page the visitor must scroll for the goal to be converted.
The lower plart is dimmed and represents the of the page that is excluded from scroll tracking.

This delimitation between the two areas gives a precise view of how far the user has to scroll to convert. The goal is converted when all of the non-dimmed page has been displayed, i.e. when the limit has reached the bottom of the screen.

You can set the level in 3 different ways.

Based on an element

By default, the scroll tracking level is set according to the element you selected to create the tracking.

The level is placed directly below the selected item. The goal is converted only if the visitor has scrolled down to reveal the entire element.

The definition in percentage is dimmed, you can’t change it.

Based on a specific percentage

By selecting “a precise percentage” from the drop-down list, changing the percentage becomes possible.

You can define the scroll tracking level as a percentage of your page.

The percentage applies to the entire page, starting from the top: 0% places the level at the very top of the page, 50% places it at half of the page and 100% at the very bottom .

The page display automatically adjusts to the percentage you enter.

You can also manually move the scroll tracking level.

Note: The percentage takes into account the entire page and not just the part currently displayed on your screen.

Place your mouse pointer on the white line that delimits the area included in the tracking. A double-headed pointer appears. Hold the left click and drag the level where you want on the page. The percentage is automatically adjusted in the tool panel.

From a height in pixels

By choosing “a height in pixels” from the drop-down menu, you can set the placement of the scroll tracking level based on a height in pixels.

The position according to a height in pixels works the same way as the placement according to a percentage. The “zero” point is at the top of the page. The lower the level on your page, the higher the pixel height, the maximum height being that of the entire page.

As for the percentage, you can manually move the level on the page by clicking and dragging the white bar. The corresponding pixel height adapts automatically.

Finalize scroll tracking

Once you have defined the scroll tracking level, click on “Add the tracking”.

By adding the tracking, you associate it with an element if you defined the level according to an element. Otherwise, the tracking is associated to the page “body” . Your tracking’s name and type (scroll) are now displayed in the list of trackings.
